FAG HCB71920-E-2RSD-T-P4S Super Precision Angular contact ball bearing
Brand:FAG
Original:GERMANY
Type:Angular contact Ball bearing
Item:FAG HCB71920-E-2RSD-T-P4S
Inner:100mm
Outner:140mm
Thickness:20mm
Weight:0.686KG
Description
FAG HCB71920-E-2RSD-T-P4S Super Precision Angular contact ball bearing with contact angle α = 25°, universal design pairs or sets used, Solid window cage made from hard fabric.
Technical data of FAG HCB71920-E-2RSD-T-P4S
ID:100mm
OD:140mm
Width:20mm
Weight:0.686kg
Basic dynamic load rating:57kN
Basic static load rating:40.5kN
Fatigue limit load:2.8kN
Limiting speed with grease lub.:9500 rpm
Part FAG Spindle bearings catalogue
HCB71920-E-2RSD-T-P4S 100*140*20
HCB71921-E-2RSD-T-P4S 105*145*20
HCB71922-E-2RSD-T-P4S 110*150*20
HCB71924-E-2RSD-T-P4S 120*165*22
HCB71926-E-2RSD-T-P4S 130*180*24
HCB71928-E-2RSD-T-P4S 140*190*24
More information please contact us.
