FAG Super Precision Angular contact ball bearing HS7013-C-T-P4S-UL
Brand:FAG
Original:GERMNAY
Type:Angular contact Ball bearing
Item:FAG HS7013-C-T-P4S-UL
Inner:65MM
Outner:100MM
Thickness:18MM
Weight:0.46KG
Description
FAG Super Precision Angular contact ball bearing HS7013-C-T-P4S-UL
Technical data of FAG HS7013-C-T-P4S-UL
ID: 65 mm
OD: 100 mm
Width: 18mm
Weight: 0.46kg
Basic dynamic load rating: 19.3kN
Basic static load rating: 13.4kN
Fatigue limit load: 1420N
Limiting speed with grease lub.: 30000 rpm
Part FAG Spindle bearings catalogue
| d | D | B | |
| mm | mm | mm | |
| HS7000-C-T-P4S | 10 | 26 | 8 |
| HS7001-C-T-P4S | 12 | 28 | 8 |
| HS7002-C-T-P4S | 15 | 32 | 9 |
| HS7003-C-T-P4S | 17 | 35 | 10 |
| HS7004-C-T-P4S | 20 | 42 | 12 |
| HS7005-C-T-P4S | 25 | 47 | 12 |
| HS7006-C-T-P4S | 30 | 55 | 13 |
| HS7007-C-T-P4S | 35 | 62 | 14 |
| HS7008-C-T-P4S | 40 | 68 | 15 |
| HS7009-C-T-P4S | 45 | 75 | 16 |
| HS7010-C-T-P4S | 50 | 80 | 16 |
| HS7011-C-T-P4S | 55 | 90 | 18 |
| HS7012-C-T-P4S | 60 | 95 | 18 |
| HS7013-C-T-P4S | 65 | 100 | 18 |
| HS7014-C-T-P4S | 70 | 110 | 20 |
| HS7015-C-T-P4S | 75 | 115 | 20 |
| HS7016-C-T-P4S | 80 | 125 | 22 |
| HS7017-C-T-P4S | 85 | 130 | 22 |
| HS7018-C-T-P4S | 90 | 140 | 24 |
| HS7019-C-T-P4S | 95 | 145 | 24 |
We are professional supplier of bearings, if you have any inquiry of FAG Bearings or other demand about bearings please contact me freely, we will support in the first time. More information please contact us.
