INA XU080149 Crossed roller bearing
Brand:INA
Original:
Type:Cross Roller bearing
Item:XU080149
Inner:101.6mm
Outner:196.85mm
Thickness:
Weight:3.6kg
Description
Due to the X arrangement of the rolling elements, INA XU080149 Crossed roller bearings can support axial forces from both directions as well as radial forces. They are very rigid, have high running accuracy and are supplied with preload.
Main product data of INA XU080149 Crossed roller bearings
without gear teeth, lip seals on both sides
| di | 101,6 mm | |
| Da | 196,85 mm | |
| m | 3,6 kg | Mass |
| Fr per | 15400 N | Maximum permissible radial load against friction lock |
| Ca | 63000 N | Basic dynamic load rating, axial |
| C0a | 66000 N | Basic static load rating, axial |
| Cr | 40000 N | Basic dynamic load rating, radial |
| C0r | 32500 N | Basic static load rating, radial |
| 0,005 – 0,02 | Bearing clearance: preload | |
| Special seal |
We can supply all following INA Crossed roller bearings XU series
| P/N | di | Da |
| XU050077 | 40 | 112 |
| XU060094 | 57 | 140 |
| XU060111 | 76,2 | 145,79 |
| XU080120 | 69 | 170 |
| XU080149 | 101,6 | 196,85 |
| XU120179 | 124,5 | 234 |
| XU120222 | 140 | 300 |
| XU160260 | 191 | 329 |
| XU080264 | 215,9 | 311 |
| XU160405 | 336 | 474 |
| XU080430 | 380 | 480 |
| XU300515 | 384 | 646 |
AMC Bearing can supply all types of INA Crossed roller bearings. These INA bearings are original Germany, brand new ones. Besides, we supply their replaced bearings of other brands. More detail bearing cross reference info,please contact us.
