NSK 6318ZZC3 Deep groove ball bearing

Brand: NSK

Original: JAPAN

Type: Deep groove ball bearing

Item:NSK 6318ZZ

Weight: 4.98KG

NSK BEARING

Description

NSK manufacture a full range of deep groove ball bearings. These bearings are the most common type and are used in a wide variety of applications.

The tech data for NSK 6318ZZC3



ORDER Bearing No.	6318ZZ
SD Inside Diameter	90	mm
D Outside Diameter	190	mm
B Width	43	mm
R Chamfer Dimension	3.0	mm
CR1 Basic Dynamic Load Ratings	143000	N
COR1 Basic Static Load Ratings	107000	N
FO Factor	13.3
LG Limiting Speed Grease	3600	rpm
DAM1 Abutment and Fillet Dimensions min.	103.0	mm
DA1 Abutment and Fillet Dimensions max.	117.0	mm
DA2 Abutment and Fillet Dimensions max.	177.0	mm
RA Abutment and Fillet Dimensions max.	2.5	mm
MASS Mass	4.980	kg

Our company is the agent of NSK bearing in China, and we have enough stock to meet your different demand. On our website there are only part of items, if you need more information about other items, please contact us soon!
