NSK 6800ZZ Deep groove ball bearing
Brand: NSK
Original: JAPAN
Type: Deep groove ball bearing
Item:NSK 6800ZZ
Weight: 0.005KG
Description
NSK manufacture a full range of deep groove ball bearings. These bearings are the most common type and are used in a wide variety of applications.
The tech data for NSK 6800ZZ
| ORDER | 6800ZZ | |
| Bearing No. | ||
| SD | 10 | mm |
| Inside Diameter | ||
| D | 19 | mm |
| Outside Diameter | ||
| B | 5 | mm |
| Width | ||
| R | 0.3 | mm |
| Chamfer Dimension | ||
| CR1 | 1720 | N |
| Basic Dynamic Load Ratings | ||
| COR1 | 840 | N |
| Basic Static Load Ratings | ||
| FO | 14.8 | |
| Factor | ||
| LG | 34000 | rpm |
| Limiting Speed Grease | ||
| DAM1 | 12 | mm |
| Abutment and Fillet Dimensions min. | ||
| DA1 | 12 | mm |
| Abutment and Fillet Dimensions max. | ||
| DA2 | 17 | mm |
| Abutment and Fillet Dimensions max. | ||
| RA | 0.3 | mm |
| Abutment and Fillet Dimensions max. | ||
| MASS | 0.005 | kg |
| Mass |
Our company is the agent of NSK bearing in China, and we have enough stock to meet your different demand. On our website there are only part of items, if you need more information about other items, please contact us soon!
