NSK NU317ETC3 cylindrical roller bearings
Brand: NSK
Original: JAPAN
Type: cylindrical roller bearings
Item:NSK NU317ETC3
Weight: 4.61KG
Description
Technical data of NSK NU317ETC3 cylindrical roller bearings
|
ORDER
Bearing No.
|
NU317ET | ||
|
CAGE
Cage
|
Option | ||
|
SD
Inside Diameter
|
85 | ||
|
D
Outside Diameter
|
180 | ||
|
B
Width
|
41 | ||
|
R
Chamfer Dimension
|
3.0 | ||
|
R1
Chamfer Dimension
|
3.0 | ||
|
FW
Boundary Dimension
|
108.0 | ||
|
CR1
Basic Dynamic Load Ratings
|
291000 | ||
|
COR1
Basic Static Load Ratings
|
330000 | ||
|
LT
Thermal rated speed /Allowable maximum speed
|
4000 | ||
|
LM
Mechanical limit speed /Allowable maximum speed
|
– | ||
|
LG
Limiting Speed Grease
|
3400 | ||
|
LO
Limiting Speed Oil
|
4000 | ||
|
DBB1
Abutment and Fillet Dimensions min.
|
98.0 | ||
|
DBB2
Abutment and Fillet Dimensions max.
|
105 | ||
|
DA2
Abutment and Fillet Dimensions max.
|
167.0 | ||
|
RA
Abutment and Fillet Dimensions max.
|
2.5 | ||
|
RB
Abutment and Fillet Dimensions max.
|
2.5 | ||
|
MASS
Mass
|
4.610 |
