Description
| Bore diameter: | 12 mm | Precision rating: | Class 0 | |
| Outside diameter: | 28 mm | Finish/coating: | Uncoated | |
| Overall width: | 8 mm | Bearing material: | High Carbon Chrome Steel | |
| Bore type: | Round | Cage material: | Steel | |
| Closure type: | Open | Inner ring width: | 8 mm | |
| Row type & fill slot: | Single Row Non-Fill Slot | Outer ring width: | 8 mm | |
| Snap ring included: | Without Snap Ring | Maximum rpm (grease): | 26000 rpm | |
| Internal clearance: | CN | Maximum rpm (oil): | 30000 rpm | |
| Operating temperature range: | -40 to 120 ºC | Fillet radius: | 0.3 mm | |
| Dynamic load capacity: | 5100 N | Manufacturer product page: | Click here | |
| Static load capacity: | 2390 N |
