NTN 6920N Deep Groove Ball Bearing Bearings

Home NTN BEARING NTN 6920N Deep Groove Ball Bearing Bearings

NTN 6920N Deep Groove Ball Bearing Bearings

 After you order the bearings, the delivery time is about 5-7 days. You don't have to worry about out of stock at all, our inventory of NTN 6920N Bearing is large enough to meet your needs. Now when you enter the purchase you will get the best price.

NTN BEARING

Description

Deep groove ball bearings 6920N

Bearing number : 6920N

Size (mm) : 100x140x20

Brand : NTN

Bore Diameter (mm) : 100

Outer Diameter (mm) : 140

Width (mm) : 20

Bearing dimensions and specification in NTN catalogue:

d – 100 mm

D – 140 mm

B – 20 mm

C – 20 mm

rn – 0,5 mm

a – 3,3 mm

b – 1,9 mm

r min. – 1,1 mm

r0 max. – 0,6 mm

D1 – 137,6 mm

da min. – 106,5 mm

da max – 110 mm

Da max. – 133,5 mm

ra max. – 1 mm

Dx – 147 mm

Cy – 4,7 mm

Cz – 1,7 mm

rn – 0,5 mm

Weight – 0,785 Kg

Basic dynamic load rating (C) – 41 kN

Basic static load rating (C0) – 39,5 kN

(Grease) Lubrication Speed – 4 500 r/min

(Oil) Lubrication Speed – 5 300 r/min

Calculation factor (f0) – 16,4

If you need any help,please contact us freely.We will reply you immediately,thanks.
