Description
THK LMCH10L Linear Bushing
More about :THK LMCH10L
| Model No. | Ball rows | Main dimensions | Flange perpen-dicularity |
Eccentricity (max) |
Radial clearance tolerance |
Basic load rating | Mass | ||||||||||||||||
| Inscribed bore diameter | Outer diameter | Overall length | Flange diameter | Pilot | D2 | H | K | B | C | Mounting hole d1×d2×h |
Dynamic C |
Static C0 |
|||||||||||
| dr | Tolerance | D | Tolerance | L | Tolerance | D1 | Tolerance | I | Tolerance | ||||||||||||||
| mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | µm | µm | µm | N | N | g | |||||||
| LMCH6L | 4 | 6 | 0 -0.010 |
12 | 0 -0.013 |
35 | ±0.3 | 28 | 0 -0.2 |
15 | ±0.2 | 12 | 5 | 18 | 20 | — | 3.4×6×3.3 | 12 | 12 | -5 | 324 | 529 | 26 |
| LMCH8L | 4 | 8 | 15 | 45 | 32 | 20 | 15 | 5 | 21 | 24 | — | 3.4×6×3.3 | 12 | 12 | -5 | 431 | 784 | 41 | |||||
| LMCH10L | 4 | 10 | 19 | 0 -0.016 |
55 | 39 | 24.5 | 19 | 6 | 25 | 29 | — | 4.5×7.5×4.4 | 12 | 12 | -5 | 588 | 1100 | 73 | ||||
| LMCH12L | 4 | 12 | 21 | 57 | 42 | 25.5 | 21 | 6 | 27 | 32 | — | 4.5×7.5×4.4 | 12 | 12 | -5 | 657 | 1200 | 83 | |||||
| LMCH13L | 4 | 13 | 23 | 61 | 43 | 27.5 | 23 | 6 | 29 | 33 | — | 4.5×7.5×4.4 | 12 | 12 | -7 | 814 | 1570 | 106 | |||||
| LMCH16L | 5 | 16 | 28 | 70 | 48 | 32 | 28 | 6 | 34 | 31 | 22 | 4.5×7.5×4.4 | 12 | 12 | -7 | 1230 | 2350 | 180 | |||||
| LMCH20L | 5 | 20 | 0 -0.012 |
32 | 0 -0.019 |
80 | 54 | 36 | 32 | 8 | 38 | 36 | 24 | 5.5×9×5.4 | 15 | 15 | -9 | 1400 | 2750 | 219 | |||
| LMCH25L | 6 | 25 | 40 | 112 | 62 | 52 | 40 | 8 | 46 | 40 | 32 | 5.5×9×5.4 | 15 | 15 | -9 | 1560 | 3140 | 470 | |||||
As a professional Linear Motion Guide supplier, we are mainly responsible for the global sales and technical services of THK products. Our warehouses are located in HongKong and ShenZhen City, it is very convenient for demands of global market . Because there are many types of THK products, we can not upload all of them at present. More information please directly contact us.
